IP CAMERA DS-2CD1301-I 2.8mm - 720p Hikvision

Standard:

TCP/IP

Sensor:

1/4" Progressive Scan CMOS

Scanning system:

Progressive

Matrix size:

1.0Mpx

Resolution:

1280 x 720 -720p

Lens:

2.8mm

View angle:

• 92° (manufacturer data)

• 90° (our tests result)

Range of IR illumination:

30m

S/N ratio:

> 50dB

Memory card slot:

Image compression method:

H.264/MJPEG

Alarm inputs / outputs:

Audio:

Bitrate:

256 ... 2048kbps -H.264

Main stream frame rate:

25fps@720p

Network interface:

10/100 Base-T(RJ-45)

Network protocols:

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS,RTP,RTSP, RTCP, NTP, UPnP, SMTP, IGMP, IEEE 802.1x, QoS,IPv6, Bonjour

WEB Server:

Built-in

Max. number of on-line users:

6

ONVIF:

2.4

Main features:

• 3D-DNR - Digital Noise Reduction

• EXIR - high-efficiency infrared LEDs technology, which evenly covers the whole plan of both central vantage points of the scene as well as the corners

• D-WDR - Wide Dynamic Range

• ROI - improve the quality of selected parts of image

• BLC - Back Light Compensation

• Possibility to change the resolution, quality and bit rate

• Mirror - Mirror image

• Motion Detection

• Configurable Privacy Zones

• Sharpness - sharper image outlines

Mobile phones support:

Port no.: 8000 or access by a cloud (P2P)

• Android: Free applicationiVMS-4500orHik-Connect

• iOS (iPhone): Free applicationiVMS-4500orHik-Connect

Default IP address:

192.168.1.64

Default admin user / password:

admin / -

Web browser access ports:

80

PC client access ports:

Port no.: 8000 or access by a cloud (P2P) - iVMS-4200 application

Mobile client access ports:

8000

Port ONVIF:

80

RTSP URL:

• Main stream
  rtsp://192.168.1.64:554/Streaming/Channels/101/ - RTSP - without authorization
  rtsp://user:password@192.168.1.64:554/Streaming/Channels/101/ - with authorization

• Sub stream
  rtsp://192.168.1.64:554/Streaming/Channels/102/ - RTSP - without authorization
  rtsp://user:password@192.168.1.64:554/Streaming/Channels/102/ - with authorization

Color:

White

Vandal-proof:

Power supply:

• PoE (802.3af),

• 12VDC/ 290mA

Power consumption:

≤ 5.5W

Housing:

Dome, Aluminum / Plastic

"Index of Protection":

IP67

Operation temp:

-30°C ... 60°C

Dimensions:

Ø 86 x 70mm

Weight:

0.21kg

Supported languages:

English, Bulgarian, Chinese, Croatian, Czech, Danish, Estonian, Finnish, French, Greek, Spanish, Dutch, Japanese, Korean, Lithuanian, Latvian, German, Norwegian, Polish, Portuguese, Russian, Romanian, Serbian, Slovak, Slovenian, Swedish, Turkish, Hungarian, Vietnamese, Italian

Manufacturer / Brand:

Hikvision

SAP Code:

300820157

Guarantee:

3 years
